Maxon Liftgate part number 282892-01 is a tube assembly, down line, gpt pump. We have tagged this as a Maxon pump.
OEM Diagram References
This part appears in the following OEM exploded diagrams. Links open the exact diagram section in a new tab.
Part Number:
282892-01
2 manuals •
6 total references
| Section | Item # | Pages | Link |
|---|---|---|---|
| single pump assembly | 22 |
Diagram p58
Table p59
|
Open diagram |
| single pump assembly | 22 |
Diagram p61
Table p62
|
Open diagram |
| single pump assembly with max ecu and maxlink | 22 |
Diagram p67
Table p68
|
Open diagram |
| Section | Item # | Pages | Link |
|---|---|---|---|
| single pump assembly | 22 |
Diagram p58
Table p59
|
Open diagram |
| single pump assembly | 22 |
Diagram p61
Table p62
|
Open diagram |
| single pump assembly with max ecu and maxlink | 22 |
Diagram p67
Table p69
|
Open diagram |
- Gallery
- Description
Maxon Liftgate part number 282892-01 is a tube assembly, down line, gpt pump. We have tagged this as a Maxon pump.
