Waltco Liftgate WFL Series
Disclaimer: This Waltco model was only made for 1 year as it was discontinued pre-2020.
The Waltco WFL tuck-under (flipaway) liftgate offers 2,500 lb and 3,300 lb capacities and uses a dual-cylinder hydraulic system for lifting and lowering.
It features a steel platform assembly, pump unit, and electrical controls, with capacity based on evenly distributed loads and full support for OEM Waltco WFL parts.
Shop Waltco Liftgate WFL Parts by Number
Find OEM Waltco WFL Series parts. From Waltco liftgate solenoids to cylinders, and more, we have the OEM replacement parts to keep your liftgate operating smoothly.
Why Shop by Part Number?
🔹 Quick & Easy Search – Enter the part number and get instant results.
🔹 Genuine Waltco Parts – Ensure optimal performance and longevity.
🔹 Fast & Reliable Ordering – Minimize downtime with direct purchasing.
Start your search now and keep your WFL liftgate running smoothly! Need assistance? Contact our support team for expert guidance!
Search by Part Number
America trusts LiftGateMe for WALTCO WFL PARTS.
Your single source guide
Helping you and your team navigate the liftgate industry
Get in touch like it's 2024
Phone, email, live chat, and text - we're on it.
Customer Centric Growth
Your liftgate needs are our priority at liftgateMe.
Coast to Coast
Shipping throughout the USA. Expedited delivery available.
Find the best-selling WALTCO WFL PARTS.
These are America's best selling WALTCO WFL PARTS. Although these are the best sellers, there are hundreds of variations depending on your unique liftgate's model, and year.
If you need assistance, please contact us today. We're here for you.
Search by Part Number
Waltco WFL Tuck-Under Liftgate Overview
All about Waltco WFL Series Liftgate
The Waltco WFL liftgate is a flipaway-style liftgate available in 2,500 lb and 3,300 lb capacities. It is designed to raise and lower cargo using a hydraulic system with dual cylinders, with capacity based on an evenly distributed load across the platform.
Core Components and System Design
The WFL liftgate includes the following key systems and assemblies:
- Hydraulic system with cylinders, hoses, and pump unit
- Steel platform assembly supported by a torsion bar
- Lift arms and parallel arm assemblies for controlled platform movement
- Pump box and electrical controls, including solenoid and switch options
These components work together to raise and lower the platform in a controlled manner.
Operation and Load Handling
The liftgate is operated using a raise and lower control switch.
- Loads should be placed as close to the vehicle and centered on the platform as possible
- Rated capacity applies only when the load is evenly distributed across the platform surface
- The platform lowering speed is controlled by a pressure-compensating valve within the hydraulic system
Installation Requirements
The WFL liftgate must be installed according to specified mounting dimensions and procedures:
- Designed for bed heights between 46” and 56”
- Requires minimum 6” clearance between tire and mount frame
- Mounting components must be securely welded to the vehicle frame
Installation should be performed by qualified personnel to ensure proper and safe operation. Find liftgate installation near you here.
Maintenance and Inspection
Waltco specifies routine inspection and maintenance intervals:
- Inspect liftgate every 6 months or 3,000 cycles
- Check for:
- Structural damage or loose fasteners
- Hydraulic leaks in cylinders, hoses, and fittings
- Proper operation of controls
- Maintain correct hydraulic fluid level and system condition
The liftgate should also be lubricated every 120 days.
Only OEM Waltco replacement parts should be used to maintain proper function and compatibility.
Safety Considerations
Proper operation is essential for safe use:
- Do not exceed rated capacity
- Keep clear of moving components and pinch points
- Do not operate the liftgate if it shows signs of damage or improper function
All warning decals must remain in place and legible, and the owner’s manual should be kept with the vehicle.
Frequently Asked Questions
1. What capacities are available for the Waltco WFL tuck-under liftgate?
The WFL series is available in 2,500 lb and 3,300 lb capacities, based on evenly distributed loads across the platform.
2. How is the Waltco WFL liftgate operated?
The liftgate is operated using a raise and lower control switch that powers the hydraulic system to move the platform.
5. What are the installation requirements for the WFL liftgate?
- Bed heights between 46” and 56”
- Minimum 6” tire clearance
- Proper mounting with welded components to the vehicle frame
All installation should follow manufacturer instructions and be completed by qualified personnel.
6. How often should the WFL liftgate be inspected and maintained?
- Inspection every 6 months or 3,000 cycles
- Regular checks for structural condition, hydraulics, and electrical components
Routine lubrication should be performed every 120 days.
9. What should be checked during routine inspections?
Routine inspections should include:
- Structural components (welds, arms, pins)
- Hydraulic system (cylinders, hoses, leaks)
- Electrical components and controls
- Proper operation of the liftgate
Repairs should be performed by qualified personnel if any issues are found. Find liftgate repair near you here.
